Deep Cycle 4S10P 12V 60Ah Lithium Battery Pack For E Scooter
Contact Person : Huang
Phone Number : +86-13691631171
WhatsApp : +8613691631171
Minimum Order Quantity : | Negotiable | Price : | Negotiable |
---|---|---|---|
Packaging Details : | Standard Packing | Delivery Time : | 15-30days |
Payment Terms : | T/T,L/C,Western Union,Paypal and MoneyGram | Supply Ability : | 1000 Pieces per day |
Place of Origin: | CHINA | Brand Name: | Benwei |
---|
Detail Information |
|||
Type: | LiFePO4 | Voltage: | 36V |
---|---|---|---|
Capacity: | 20Ah | Cycle Life: | 2000 Times |
Protection: | Overcharge Protect | Size: | Customized |
High Light: | 12S5P E Scooter Battery Pack,LiFePO4 36 Volt 20Ah Lithium Battery,E Scooter 36 Volt 20Ah Lithium Battery |
Product Description
Feature:
1. Long cycle life, large capacity and good shock resistance
2. Low self-discharge and good discharge performance at low temperature
3. Strong charging acceptance and quick-charging capability
4. Strong over-discharge resistance and charge retention
5. Maintenance-free and no acid or water for maintenance in usage
6. Excellent large current discharge performance, and have obvious advantages in start up and climbing
7. High temperature performance, can up to 75℃
8. Environmental friendly
9. Lighter weight smaller size
10. Most safe no explosion no fire
Specifications:
Item |
General Parameter |
Remark |
Model |
36V 20Ah lifepo4 battery |
12S5P 32700 LFP cell |
Nominal Capacity |
30Ah |
|
Nominal Voltage |
36V |
Mean Operation Voltage |
Weight |
Around 9Kg |
|
Dimension |
230*195*170mm |
Customized |
Charge |
Standard Charge Current 5.0A |
Charge timeApprox 6h |
Maximum Charge Current 10.0A |
Charge timeApprox 4h |
|
Charge Voltage 43.8V |
||
Discharge |
Continuous Discharge Current ≤30.0A |
|
Maximum Instantaneous Discharge Current ≤90.0A |
||
Discharge Cut-off Voltage 26.4V |
||
Operation Temperature |
Charge Temperature 0~45℃ |
|
Discharge Temperature-10~60℃ |
||
Over Charge Protection Voltage |
3.65V±25mV |
|
Over Charge Recovery Voltage |
3.50V±25mV |
|
Over Discharge Protection Voltage |
2.0V±25mV |
|
Over Discharge Recovery Voltage |
2.3V±25mV |
|
Over Current Protection Current |
120A |
