25.6V 40Ah AGV RGV LiFePO4 Battery Pack Lithium Iron Phosphate type
Contact Person : Huang
Phone Number : +86-13691631171
WhatsApp : +8613691631171
Minimum Order Quantity : | Negotiable | Price : | Negotiable |
---|---|---|---|
Packaging Details : | Standard Packing | Delivery Time : | 15-30days |
Payment Terms : | T/T,L/C,Western Union,Paypal and MoneyGram | Supply Ability : | 1000 Pieces per day |
Place of Origin: | CHINA | Brand Name: | Benwei |
---|
Detail Information |
|||
Battery Cell: | 3.2V 6Ah LifePO4 Battery Cell | Configuration: | 12S9P |
---|---|---|---|
Case Material: | ABS+PC | Nominal Voltage: | 36V |
Nominal Capacity: | 50Ah | Charge Method: | CC/CV |
High Light: | 36V 50Ah LiFePO4 Battery Pack,100mA LiFePO4 Golf Cart Battery,12S9P LiFePO4 Golf Cart Battery |
Product Description
Model | ML-32700/12S9P |
Battery cell | 3.2V 6Ah LifePO4 battery cell |
Battery configuration | 12S9P(12 series,9 parallel) |
Case dimension | 329*172*217mm(L*W*H) |
Case material | ABS+PC |
Nominal voltage | 36V |
Nominal capacity | 50Ah |
Internal resistance | ≤220m |
End of charge voltage | 43.8V |
End of discharge voltage | 32V |
End of charge current | 100mA |
Charge method | CC/CV |
Standard charge current | 10A |
Max charge current | 25A |
Standard discharge current | 25A |
Max continuous discharge current | 60A |
Max pulse discharge current | 120A |
Net weight | 14KG |
Terminal | M8 connector |
Charge temperature | 0~45℃ |
Discharge temperature | -10~55℃ |
Storage temperature | -10~45℃ |
Lifecycle | 2000 times |
Warranty | 3 years |
BMS protection | over-charge,over-discharge,over-current,short circuit and balance function |
Advantages of 36V 50Ah LifePO4 battery:
1. Green energy, Non-toxic, non-polluting, a wide range of raw materials, cheap
2. Long life cycle over 2000 times;
3. It without heavy metals and environment friendly.
4. Maintenance free
5. Internal BMS with full protection, the battery has high voltage protection with higher reliability.
6. No memory effect
7. High-temperature performance is good
9. High safety, no explosion, no fire
10. Low self-discharge rate,≤3%/month
Applications :
Wheelchairs and scooters
Solar/wind energy storage
Back-up power for small UPS
Golf trolleys & buggies
Electric bikes
