Product Description:
LiFePO4 Lithium iron phosphate battery are designed as the drop-in replacement for the similar capacity of lead-acid batteries, it offering twice of the run-time but only half of the weight. Moreover, it with non-toxic and non-polluting, Eco-friendly, good thermal stability, and longer run-time features.
Application :
UPS, Golf Cart, Solar-Wind Power System ,Irrigation solar system,solar street led lighting ,City Grid (On/Off), Community and Family, Marine, Boat telecom Base, CATV system, Computer Server Center, Medical Instrument, Military Equipment etc.
Communication :
With RS485/RS432 ,can connected with your solar system.
Specifications:
|
Cells
|
LiFePo4 cells
|
|
Nominal voltage
|
51.2V
|
|
Working Voltage Range
|
36V-57.6V
|
|
End of Charge voltage
|
57.6V+/- 0.05V
|
|
Max Capacity
|
50Ah
|
|
Continuous discharging current
|
20A
|
|
Continuous charging current
|
20A
|
|
Shelf life
|
6 month typically before recharging
|
|
Temperature shut down
|
60°C (Charge/discharge)
|
|
Operating temperature
|
Charging: 0°C ~ 45°C
|
|
Discharging: -20°C ~ 60°C
|
|
Storage temperature/humidity
|
Temperature -10°C ~ +35°C;Humidity 65%±20%RH
|
|
Dimension
|
483(L)x420(W)x133.5(H)
|
|
Weight
|
Around 28kg
|
|
Battery BMS
|
Built-in Smart BMS with RS232 / RS485
|
Why choose us?
We do custom batteries according to your request.
Voltage from 3.2v to 48v
Capacity from 600mah to 150ah
Discharge rate: normal, 2C,3C,5C,10C,20C, etc.
We can customize the battery for you, send an inquiry with the below information now!
Battery information Appliance information
Size Appliance name
Capacity Normal working current
Cable length Peak current
Connector Working voltage range
Why choose us?
We do custom batteries according to your request.
Voltage from 3.2v to 48v
Capacity from 600mah to 150ah
Discharge rate: normal, 2C,3C,5C,10C,20C, etc.
We can customize the battery for you, send an inquiry with the below information now!
Battery information Appliance information
Size Appliance name
Capacity Normal working current
Cable length Peak current
Connector Working voltage range
Advantages of LifePO4 battery:
1. Green energy, Non-toxic, non-polluting, a wide range of raw materials, cheap
2. Long life cycle over 2000 times;
3. It without heavy metals and environment friendly.
4. Maintenance free
5. Internal BMS with full protection, the battery has high voltage protection with higher reliability.
6. No memory effect
7. High-temperature performance is good
9. High safety, no explosion, no fire
10. Low self-discharge rate,≤3%/month
1. Green energy, Non-toxic, non-polluting, a wide range of raw materials, cheap
2. Long life cycle over 2000 times;
3. It without heavy metals and environment friendly.
4. Maintenance free
5. Internal BMS with full protection, the battery has high voltage protection with higher reliability.
6. No memory effect
7. High-temperature performance is good
9. High safety, no explosion, no fire
10. Low self-discharge rate,≤3%/month
