Sealed Lead Acid 12V 120Ah LiFePO4 Battery Pack With BMS System

Minimum Order Quantity : Negotiable Price : Negotiable
Packaging Details : Standard Packing Delivery Time : 15-30days
Payment Terms : T/T,L/C,Western Union,Paypal and MoneyGram Supply Ability : 1000 Pieces per day
Place of Origin: CHINA Brand Name: Benwei
Model Number: 12V 120Ah LiFePo4 Battery

Detail Information

Product Name: 12V 120Ah LiFePo4 Battery Pack Long Service Life: 3500+
Nominal Voltage: 72V Standard Charging Time: About 5h
Total Weight: About 12kg OEM/ODM: Available
High Light:

12V120Ah LiFePO4 Battery Pack


BMS LiFePO4 Battery Pack


12V 120Ah Lithium Battery

Product Description

Sealed Lead Acid 12V 120Ah LiFePO4 Battery Pack With BMS System


Lithium Battery 12V 120Ah LiFePo4 Battery With BMS System Lifepo4 RV Replacement Sealed Lead Acid Battery


12V 120Ah Lithium Battery Features:

1. 12V 120Ah LiFePo4 Battery

2. Long service life 3500+

3. Low self-discharge;

4. Environment friendly;

5. Good safety performance;

6. Maintenance-free operation;

7. Broad operating temperature range.


Normal performance of 12V 120Ah LiFePO4 Battery Pack:

Item Parameter Remark
Model 3.2V 6Ah lifepo4 Single-cell
Casing material for single cell Nickel-plated steel
Standard capacity 120Ah 0.2C
Rated voltage 12.8V 3.20V
(Work voltage:3.20V)
Max.Charge voltage 14.6V 3.65V
(Single Ave. charge Volt)
Cut-off voltage 10V 2.50V
(Single Ave. Discharge Voltage)
Standard charge current 24A 0.2C
Standard charging Time About 5h 0.2C
Max Continuous discharge current 120A Can be customized
Peak discharge current 150A Can be customized
Battery dimension 328*171*215mm Customized
Total weight About 12kg
Charge method (CC/CV) Charge 0℃~45℃
Discharge -20℃~45℃
Storage -20℃~45℃


Advantages of LiFePO4 Battery Pack

1. Long cycle life: with more than 3000 cycles, normal life time is more than 10 years.

2. Safety: The battery have built-in BMS to monitor the battery status and carry on protection to the battery.

3. Smaller size with larger capacity: Compared with Lead-acid battery, LiFePO4 battery is about 1/3 size and weight of it.

4. Excellent performance even in high temperature.
5. With high retention rate (2000 cycles 80%) and low self-discharge(less than 3%).
