Item
|
Product parameters
|
|
Mode
|
ML -9.6V-20AH
|
|
Size
|
MAX:105mm*40mm*225mm
|
|
Charge voltage
|
10.95V
|
| Nominal voltage |
9.6V |
| Nominal capacity |
20Ah (Customizable) |
| Charge current |
Standard Charging: 0.2C/Rapid charging: 1.0C |
|
Charging method
|
0.2C(constant current)charge to 10.95V,then CV(constant voltage10.95V)charge till charge current decline to≤0.2C
|
| Charging time |
Standard Charging:5.0hours(Ref.)/Rapid charge:1.0hours(Ref.) |
| Max.charge current |
1C/A |
| Max.discharge current |
3C/A |
| Discharge cut-off voltage |
8.25V |
| Operating temperature |
-20℃ ~ 70℃ |
Features:
1. The size is flexible and random, and it can be assembled according to the customer's specified requirements
2. A wide range of optional capacity, multi-parallel multi-string battery packs can be customized, wider selection and longer use
3. High discharge platform, stable voltage, low internal resistance, fast charging time
4. The batteries are accurately paired, with long service life, and the number of cycles is higher than 2000 times
5. Very high safety, with overcharge protection, over-discharge protection, and overcurrent protection
Remarks: The battery assembly method requirements can be customized according to customer requirements, such as voltage, capacity, packaging color, matching plugs, etc.
FAQ:
Q.Can I have a sample order for Battery?
A: Yes, we welcome sample orders to test and check quality.
Q.What about the lead time?
A: Sample needs 10-15 days, neutral order mass production time needs 15-20 working days. If OEM orders would be about 20-30days.
Q: Can we visit the Manly factory?
A: Warmly welcome. Our factory located in Shenzhen, very close to Guangzhou or Hongkong.
Why choose us?
We do custom batteries according to your request.
Voltage from 3.2v to 48v
Capacity from 600mah to 150ah
Discharge rate: normal, 2C,3C,5C,10C,20C, etc.
