Product Details:
1. High energy density; High working voltage for single battery cells
2. Pollution-free; No memory effect
3. Cycle life can easily reach 2000 times and over
4. Capacity, resistance, Voltage, platform time consistency is good
5. With short-circuit production function, safe and reliable
6. Factory price& High quality
7. Good consistency, low self discharge
8. Light weight, small size
|
Item
|
Unit
|
Parameters
|
Remark
|
|
Battery Type
|
Lifepo4 Lithium Batteries
|
|
Nominal Capacity
|
Ah
|
7.0
|
Capacity according to standard discharge, After standard charge
|
|
Nominal Voltage
|
V
|
6
|
Average Voltage according to standard discharge, After standard charge
|
|
Charge Type
|
/
|
CC/CV
|
/
|
|
Charge Cut-off Voltage
|
V
|
7.24
|
/
|
|
Discharge Cut-off Voltage
|
V
|
5
|
/
|
|
Charge current
|
A
|
1C
|
MAX or customized
|
|
Constant discharge current
|
A
|
0.2C
|
Standard or customized
|
|
Peak discharge current
|
A
|
3C
|
Max or customized
|
|
Weight
|
KG
|
Around 0.7
|
/
|
|
Dimension
|
mm
|
/
|
Customized
|
|
Working Temperature
|
°C
|
Charging:0~45
|
/
|
|
°C
|
Discharging:-20~60
|
/
|
|
Storage Temperature
|
°C
|
0~45
|
/
|
Why choose us?
We do custom batteries according to your request.
Voltage from 3.2v to 48v
Capacity from 600mah to 150ah
Discharge rate: normal, 2C,3C,5C,10C,20C, etc.
We can customize the battery for you, send an inquiry with the below information now!
Battery information Appliance information
Size Appliance name
Capacity Normal working current
Cable length Peak current
Connector Working voltage range
Advantages of LifePO4 battery:
1. Green energy, Non-toxic, non-polluting, a wide range of raw materials, cheap
2. Long life cycle over 2000 times;
3. It without heavy metals and environment friendly.
4. Maintenance free
5. Internal BMS with full protection, the battery has high voltage protection with higher reliability.
6. No memory effect
7. High-temperature performance is good
9. High safety, no explosion, no fire
10. Low self-discharge rate,≤3%/month
Application: Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Forklifts, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies
