Features
Shockproof: through the plastic shell shockproof structure design, meet the requirements of high safety, waterproof, and high reliability;
Salt spray: To achieve resistance to salt spray mold, suitable for the marine working environment.
The battery pack has a high cycle life, which is in line with the values of low carbon, energy-saving, and environmental protection;
|
Electrical Characteristics
|
Battery pack Nominal Voltage
|
12.8V
|
|
Battery pack Nominal capacity
|
75Ah
|
|
Battery pack Energy
|
960Wh
|
|
Internal Resistance
|
≤30m
|
|
Battery pack Cycle life
|
≥4000 cycles @1C 100%DOD
|
|
Months Self Discharge
|
<3%
|
|
Efficiency of Charge
|
100% @0.5C
|
|
Efficiency of Discharge
|
96~99% @1C
|
|
Standard Charge
|
Charge Voltage
|
14.6±0.2V
|
|
LiFePO4 Battery Charge Mode
|
0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV)
|
|
Battery pack standard Charger Current
|
37.5A
|
|
Battery pack charging time
|
about 3h
|
|
Charge Cut-off voltage
|
10V±0.2V
|
|
Standard Discharge
|
Max Continuous discharge Current
|
75A
|
|
Peak discharge current
|
150A
|
|
Environmental
|
Charge Temperature
|
0to 45(32F to 113F) @60±25% Relative Humidity
|
|
Discharge Temperature
|
-20to 60(-4F to 140F) @60±25% Relative Humidity
|
|
Storage Temperature
|
25℃ (32F to 104F) @60±25% Relative Humidity
|
|
Water Dust Resistance
|
IP65
|
|
Mechanical
|
Cell & Method
|
4S1P
|
|
Plastic Case
|
ABS
|
|
Dimensions (mm)
|
260*170*220m
|
Advantages of LifePO4 battery:
1. Green energy, Non-toxic, non-polluting, a wide range of raw materials, cheap
2. Long life cycle over 2000 times;
3. It without heavy metals and environment friendly.
4. Maintenance free
5. Internal BMS with full protection, the battery has high voltage protection with higher reliability.
6. No memory effect
7. High-temperature performance is good
9. High safety, no explosion, no fire
10. Low self-discharge rate,≤3%/month
Why choose us?
We do custom batteries according to your request.
Voltage from 3.2v to 48v
Capacity from 600mah to 150ah
Discharge rate: normal, 2C,3C,5C,10C,20C, etc.
We can customize the battery for you, send an inquiry with the below information now!
Battery information Appliance information
Size Appliance name
Capacity Normal working current
Cable length Peak current
Connector Working voltage range
Application: Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Forklifts, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies
