12V 7Ah Lifepo4 Battery Cell UPS System Lithium Iron Phosphate Cell
Contact Person : Huang
Phone Number : +86-13691631171
WhatsApp : +8613691631171
Minimum Order Quantity : | Negotiable | Price : | Negotiable |
---|---|---|---|
Packaging Details : | Standard Packing | Delivery Time : | 15-30days |
Payment Terms : | T/T,L/C,Western Union,Paypal and MoneyGram | Supply Ability : | 1000 Pieces per day |
Place of Origin: | CHINA | Brand Name: | Benwei |
---|
Detail Information |
|||
Capacity: | 36Ah | Voltage: | 12.8V |
---|---|---|---|
Energy: | 460.8Wh | Max Charge Current: | 1C |
Peak Discharge Current: | 3C | Cell Model: | 3.2V 6Ah |
Weight: | About 3.7kg | Configuration: | 4S6P |
High Light: | 4S6P Battery Pack For Solar Lights,12V 36Ah Battery Pack For Solar Lights,12V 36Ah Rechargeable Battery |
Product Description
Features:
1. Eco-friendly, no pollution
2. Longer life compared to Lead-Acid battery
3. Up to 70% weight savings
4. More than 2000 cycles of charge and discharge
5. Support fast shipping and get samples
Specifications:
Deep cycle rechargeable 12.8v/12v 36ah LFP lifepo4 battery for solar light |
|||
Electric Characteristics |
|||
Capacity |
36Ah |
Energy |
460.8Wh |
Voltage |
12.8V |
||
Internal Resistance |
≤50m |
Cycle Life |
≥2000 times |
Charging and Discharging Parameters |
|||
Charge cut-off voltage |
14.6V |
Discharge cut-off voltage |
10V |
Max Charge current |
1C |
Standard Discharge current |
0.2C |
Peak Discharge current |
3C |
Suggested charge Voltage |
14.6V |
|
|
||
Charge |
0~45℃ |
Less than a year |
0~25℃ |
Discharge |
-20~60℃ |
Less than three months |
-10~35℃ |
Recommended |
18~28℃ |
||
Mechanical Properties |
|||
Housing materials |
PVC |
Cell model |
3.2v 6ah |
Weight |
About 3.7kg |
Configuration |
4S6P |
BMS |
|||
Protect battery from Over charge, Over-discharge, Over-current, Short circuit |
Application:
UPS system
Telecommunication system
Power station system
Railway system
Emergency lighting system
Automatic control system
Alarm systems for fire protection ,security
Solar,wind powered systems
Electric instruments
Advantages of LifePO4 battery:
1. Green energy, Non-toxic, non-polluting, a wide range of raw materials, cheap
2. Long life cycle over 2000 times;
3. It without heavy metals and environment friendly.
4. Maintenance free
5. Internal BMS with full protection, the battery has high voltage protection with higher reliability.
6. No memory effect
7. High-temperature performance is good
9. High safety, no explosion, no fire
10. Low self-discharge rate,≤3%/month
* Lithium iron phosphate battery is characterised by outstanding durability, current performance and charging speed. It also has a longer lifetime and is a more lightweight alternative to lead-acid batteries.
* LiFePO4 retain over 80% of their capacity even after 3,000 charging cycles and thus they provide over 7 years of operation. Due to its low self-discharge rate the battery will be fully ready for operation even after a year of storage.
* The long battery life and high durability, low weight and current parameters are the reasons why these batteries are used in leisure vehicles and campers, in boats and in photovoltaics providing power to homes using solar panels.
* Lithium iron phosphate batteries are equipped with a battery management system BMS which monitors not only the charge and discharge of the battery but also the temperature thus ensuring the safety of operation and maximising the battery life.
