Main Feature Of This Battery Lithium Lifepo4:
1. Weight Is Only About 900g But Capacity Is 30ah;
2. Grade A China Cells] High End Cells Even It’S A China Brand, Performance Is Good, Very Safe But Price Is More Competitive;
3. This Battery Is With Over 2000 Time Charge And Discharge Cycle Life, After That, Capacity Left Is Still 80% Of Original Value, Self Discharge Rate Is Much Lower Than Li-Ion Battery.;
4. Battery Cells, Size, Capacity, Voltage, Connector…Most Parameters Can Be Changed According To Your Request.
Product Description:
|
ITEM
|
SPECIFICATION
|
REMARK
|
|
Nominal Voltage
|
3.2V
|
|
|
Nominal Capacity
|
30Ah
|
Standard discharge at 0.2C
|
|
Standard Discharge Current
|
0.2C (6A)
|
|
|
Max Continuous Discharge Current
|
2C(60A)
|
|
|
Peak Current
|
70A
|
last time≤1s
|
|
Charge Voltage
|
3.65± 0.05V
|
|
|
Standard Charge Current
|
0.2C (6A)
|
Charge timeApprox 7.0h
|
|
Fast Charge Current
|
1C(30A)
|
Charge timeApprox 3.0h
|
|
Inner Resistance
|
≤45m
|
AC 1KHZ after 50% charge
|
|
Cycle life
|
≥2000 times until 80% capacity
|
|
Ref. Discharge Cut off Voltage
|
2.0± 0.05V
|
|
|
Charge Temperature Range
|
0°C to 45°C
|
|
|
Discharge Temperature Range
|
-20°C to 60°C
|
|
|
Recommended Storage Temperature
|
35°C
|
|
|
Weight
|
Approx. 900g
|
|
|
Battery Cell Model
|
32700
|
|
|
Configuration
|
1S5P
|
|
|
Battery PCM function
|
Over charge/discharge,over current, short circuit protection
|
Advantages of LifePO4 battery:
1. Green energy, Non-toxic, non-polluting, a wide range of raw materials, cheap
2. Long life cycle over 2000 times;
3. It without heavy metals and environment friendly.
4. Maintenance free
5. Internal BMS with full protection, the battery has high voltage protection with higher reliability.
6. No memory effect
7. High-temperature performance is good
9. High safety, no explosion, no fire
10. Low self-discharge rate,≤3%/month
Advantages of LifePO4 battery:
1. Green energy, Non-toxic, non-polluting, a wide range of raw materials, cheap
2. Long life cycle over 2000 times;
3. It without heavy metals and environment friendly.
4. Maintenance free
5. Internal BMS with full protection, the battery has high voltage protection with higher reliability.
6. No memory effect
7. High-temperature performance is good
9. High safety, no explosion, no fire
10. Low self-discharge rate,≤3%/month
* Lithium iron phosphate battery is characterised by outstanding durability, current performance and charging speed. It also has a longer lifetime and is a more lightweight alternative to lead-acid batteries.
* LiFePO4 retain over 80% of their capacity even after 3,000 charging cycles and thus they provide over 7 years of operation. Due to its low self-discharge rate the battery will be fully ready for operation even after a year of storage.
* The long battery life and high durability, low weight and current parameters are the reasons why these batteries are used in leisure vehicles and campers, in boats and in photovoltaics providing power to homes using solar panels.
* Lithium iron phosphate batteries are equipped with a battery management system BMS which monitors not only the charge and discharge of the battery but also the temperature thus ensuring the safety of operation and maximising the battery life.
ShenZhen Benwei Lighting Technolohgy Co., Ltd
Benwei Company has four production lines for solar battery, motorcycle battery, Electric vehicle battery,RV battery and Motorcycle start battery. With Incoming material inspection area to test the materials to ensure the every battery packs are good quality.
